Bootstrap 02.09 **Small NAS Series** ** LOADER ** ** Buffalo BOARD: MVISAH -xx Hassi Board LE ** U-boot Version 1.02L-1.00 ** Build Date Jun 11 2007-11:39:48 U-Boot 1.1.4 (Jun 11 2007 - 11:39:53) Marvell version: 2.2.4-TINY-NQ U-Boot code: 00200000 -> 0023EE00 BSS: -> 0024A420 Soc: 88F6082 A1 (DDR1) CPU running @ 333Mhz SysClock = 166Mhz , TClock = 133Mhz DRAM CS[0] base 0x00000000 size 8MB DRAM CS[1] base 0x01000000 size 8MB DRAM Total size 16MB [256kB@f8100000] Flash: 256 kB Addresses 4M - 0M are saved for the U-Boot usage. Mem malloc Initialization (4M - 3M): Done CPU : ARM926 (Rev 0) misc_init_r_env u-boot stop condition :MagicKey =(67, 24, 58, 2, 92, 113, 0) misc_init_r_env > fHddBootWaitEnabled Please Press HDD power button to continue ...ここまで進む。
USB 0: device mode
DDR SDRAM Pads Driving Nch (Manu) = c
DDR SDRAM Pads Driving Pch (Manu) = c
DDR SDRAM Drive Strength 0-3 = 3
DDR SDRAM Pads Driving Nch (Auto) = c
DDR SDRAM Pads Driving Pch (Auto) = c
Using 88E1112 phy
Marvell Serial ATA Adapter
Integrated Sata device found
Device 0: OK
Model: SAMSUNG HD501LJ Firm: CR100-10 Ser#: S0Z4J1FPA01351
Type: Hard Disk
Supports 48-bit addressing
Capacity: 476940.0 MB = 465.7 GB (976773168 x 512)
Net: egiga0 [PRIME], egiga1
hit any key to switch tftp boot.
Hit any key to stop autoboot: 0
:
:
とブートへ進む。
BUFFALO INC. LinkStation series LS-LGL(SUIZEI)
LS-LGLFF7 login: CPU_STAT=normal_state
##### shutdown start
Starting pid 1129, console /dev/ttyS0: '/etc/init.d/rcDown'
--- rcDown ---
===== exec:fwupdate_check.sh =====
fw udpate not detected. normally shutting down / reboot.
===== exec:shutdown_start.sh =====
CPU_STAT=
##### shutdown delayed cause present status is not a normal
called shutdown_start /etc/init.d/shutdown_start.sh
===== exec:shutdown_proc.sh =====
Stop clientUtil_server:===== exec:save_config.sh =====
Save current configuration files
tar: Removing leading '/' from member names
tar: Removing leading '/' from member names
===== exec:umount_disk.sh =====
killing all servers..
$Shutting down SMB services:
$Shutting down NMB services:
killing all daemons
killall: sshd: no process killed
\n==== unmounting all disks ====
umount2: Invalid argument
umount: /mnt/usbdisk1: Illegal seek
umount2: Invalid argument
umount: /mnt/usbdisk2: not mounted
umount: /dev/usbdisk1_1: not found
umount: /dev/usbdisk2_1: not found
===== exec:sendsigs.sh =====
no syslogd
umount: /: device is busy
umount: /: device is busy
umount: /: device is busy
Starting pid 1282, console /dev/ttyS0: '/bin/umount'
umount: /: device is busy
umount: /: device is busy
umount: /: device is busy
The system is going down NOW !!
Sending SIGTERM to all processes.eth0: link down
Sending SIGKILL to all processes.
The system is halted.
eth0: link up<5>, full duplex<5>, speed 1 Gbps<5>
Synchronizing SCSI cache for disk sda:
System halted.
BuffaloChangePowerStatusBeforeHalt > Chech Power status. Magic Key = 2
BuffaloChangePowerStatusBeforeHalt > Changed to 122 from 2
Bootstrap 02.09
**Small NAS Series**
** LOADER **
** Buffalo BOARD: MVISAH -xx Hassi Board LE
** U-boot Version 1.02L-1.00
** Build Date Jun 11 2007-11:39:48
U-Boot 1.1.4 (Jun 11 2007 - 11:39:53) Marvell version: 2.2.4-TINY-NQ
U-Boot code: 00200000 -> 0023EE00 BSS: -> 0024A420
Soc: 88F6082 A1 (DDR1)
CPU running @ 333Mhz
SysClock = 166Mhz , TClock = 133Mhz
DRAM CS[0] base 0x00000000 size 8MB
DRAM CS[1] base 0x01000000 size 8MB
DRAM Total size 16MB
[256kB@f8100000] Flash: 256 kB
Addresses 4M - 0M are saved for the U-Boot usage.
Mem malloc Initialization (4M - 3M): Done
CPU : ARM926 (Rev 0)
misc_init_r_env 861 > MagicKey Change to 92
misc_init_r_env u-boot stop condition :MagicKey =(67, 24, 58, 2, 92, 113, 0)
misc_init_r_env > fHddBootWaitDisabled
USB 0: device mode
DDR SDRAM Pads Driving Nch (Manu) = c
DDR SDRAM Pads Driving Pch (Manu) = c
DDR SDRAM Drive Strength 0-3 = 3
DDR SDRAM Pads Driving Nch (Auto) = c
DDR SDRAM Pads Driving Pch (Auto) = c
Using 88E1112 phy
Marvell Serial ATA Adapter
Integrated Sata device found
Device 0: OK
Model: SAMSUNG HD501LJ Firm: CR100-10 Ser#: S0Z4J1FPA01351
Type: Hard Disk
Supports 48-bit addressing
Capacity: 476940.0 MB = 465.7 GB (976773168 x 512)
Net: egiga0 [PRIME], egiga1
hit any key to switch tftp boot.
Hit any key to stop autoboot: 0
Hit any key to stop autoboot: 0
1284172 bytes read
1477002 bytes read
## Booting image at 01200000 ...
Image Name: Linux-2.6.12.6-arm1
Created: 2007-11-13 2:16:10 UTC
Image Type: ARM Linux Kernel Image (uncompressed)
Data Size: 1284108 Bytes = 1.2 MB
Load Address: 00008000
Entry Point: 00008000
Verifying Checksum ... OK
OK
## Loading Ramdisk Image at 013fffc0 ...
Image Name: initrd
Created: 2007-11-13 2:16:17 UTC
Image Type: ARM Linux RAMDisk Image (gzip compressed)
Data Size: 1476938 Bytes = 1.4 MB
Load Address: 00000000
Entry Point: 00000000
Verifying Checksum ... OK
Starting kernel ...
CONFIG_BUFFALO_PLATFORM CONFIG_BUFFALO_LINKSTATION_LSLGL ---
Uncompressing Linux.................................................................................... decompress done, booting the kernel.
Linux version 2.6.12.6-arm1 (root@build.dd-hot24.nas.buffalo.local) (gcc version 3.4.4 (release) (CodeSourcery ARM 2005q3-2)) #4 Tue Nov 13 11:16:02 JST 2007
CPU: ARM926EJ-Sid(wb) [41069260] revision 0 (ARMv5TEJ)
CPU0: D VIVT write-back cache
CPU0: I cache: 16384 bytes, associativity 1, 32 byte lines, 512 sets
CPU0: D cache: 16384 bytes, associativity 1, 32 byte lines, 512 sets
Machine: Feroceon
Using UBoot passing parameters structure
Sys Clk = 166666667, Tclk = 133333333
Memory policy: ECC disabled, Data cache writeback
Built 1 zonelists
Kernel command line: console=ttyS0,115200 root=/dev/sda2 rw initrd=0x01400000,4M panic=5 BOOTVER=1.02L
PID hash table entries: 128 (order: 7, 2048 bytes)
Console: colour dummy device 80x30
Dentry cache hash table entries: 4096 (order: 2, 16384 bytes)
Inode-cache hash table entries: 2048 (order: 1, 8192 bytes)
Memory: 8MB 8MB 0MB 0MB = 16MB total
Memory: 9416KB available (2186K code, 361K data, 96K init)
Mount-cache hash table entries: 512
CPU: Testing write buffer coherency: ok
checking if image is initramfs...it isn't (no cpio magic); looks like an initrd
Freeing initrd memory: 4096K
NET: Registered protocol family 16
CPU Interface
-------------
SDRAM_CS0 ....base 00000000, size 16MB
SDRAM_CS1 ....base 01000000, size 16MB
PEX0_MEM ....base e0000000, size 128MB
PEX0_IO ....base f2000000, size 1MB
INTER_REGS ....base f1000000, size 1MB
NFLASH_CS ....base f9000000, size 2MB
MFLASH_CS ....base f8100000, size 256KB
SPI_CS ....base fa000000, size 8MB
BOOT_ROM_CS ....base fc000000, size 1MB
DEV_BOOTCS ....base fc000000, size 1MB
CRYPT_ENG ....base f0000000, size 64KB
mv_mtd_initialize Error : Unknown board
Marvell Development Board (LSP Version 2.1.10_TG)-- RD-88F6082-DAS-PLUS Soc: MV88F6082 Rev 1
Detected Tclk 133333333 and SysClk 166666667
Marvell USB EHCI Gadget controller #0: c02efbc0
mvPexBarSet: ERR. Target 2 window invalid
mvPexInit: ERR. mvPexBarSet 2 failed
pci_init:Error calling mvPciIfInit for pciIf 0
IO Request resource failed - Pci If 0
PCI: bus0: Fast back to back transfers enabled
SCSI subsystem initialized
Fast Floating Point Emulator V0.9 (c) Peter Teichmann.
inotify device minor=63
SGI XFS with no debug enabled
Serial: 8250/16550 driver $Revision: 1.90 $ 4 ports, IRQ sharing disabled
ttyS0 at MMIO 0x0 (irq = 3) is a 16550A
io scheduler noop registered
RAMDISK driver initialized: 3 RAM disks of 5120K size 1024 blocksize
loop: loaded (max 8 devices)
Marvell Gigabit Ethernet Driver 'egiga':
o Ethernet descriptors in DRAM
o DRAM SW cache-coherency
o Checksum offload enabled
o Marvell ethtool proc enabled
o Rx desc: 64
o Tx desc: 128
o Loading network interface 'eth0' 'eth1'
Intergrated Sata device found
scsi0 : Marvell SCSI to SATA adapter
Vendor: SAMSUNG Model: HD501LJ Rev: CR10
Type: Direct-Access ANSI SCSI revision: 03
SCSI device sda: 976773168 512-byte hdwr sectors (500108 MB)
SCSI device sda: drive cache: write back
SCSI device sda: 976773168 512-byte hdwr sectors (500108 MB)
SCSI device sda: drive cache: write back
sda: sda1 sda2 sda4 < sda5 sda6 >
Attached scsi disk sda at scsi0, channel 0, id 0, lun 0
Attached scsi generic sg0 at scsi0, channel 0, id 0, lun 0, type 0
physmap flash device: 40000 at f8100000
Marvell Flash Detected @ 0xf8100000, 256KB Main region (64sec x 4KB), 2KB Information region
mice: PS/2 mouse device common for all mice
mvGppValueSet: Err. An attempt to set output value to GPP 3 in input mode.
Buffalo Platform Linux Driver(Light) (C) BUFFALO INC. Ver.0.01 installed.
Kernel message queue controll (C) BUFFALO INC. Ver.1.00 installed.
Kernel event for procfs (C) BUFFALO INC. Ver.1.00 installed.
Buffalo CPU Inerupts Driver (C) BUFFALO INC. Ver.0.01 alpha1 installed.
NET: Registered protocol family 2
IP: routing cache hash table of 512 buckets, 4Kbytes
TCP established hash table entries: 1024 (order: 1, 8192 bytes)
TCP bind hash table entries: 1024 (order: 0, 4096 bytes)
TCP: Hash tables configured (established 1024 bind 1024)
NET: Registered protocol family 1
NET: Registered protocol family 17
RAMDISK: Compressed image found at block 0
EXT2-fs warning: checktime reached, running e2fsck is recommended
VFS: Mounted root (ext2 filesystem).
---- in linuxrc ---
\n==== unmounting all disks ====
umount2: No such file or directory
umount: /boot: Illegal seek
umount2: No such file or directory
umount: /mnt/disk1/: Illegal seek
umount2: No such file or directory
umount: /mnt/usbdisk1: Illegal seek
umount2: No such file or directory
umount: /mnt/usbdisk2: not found
umount: /dev/usbdisk1_1: not found
umount: /dev/usbdisk2_1: not found
umount: /boot: not found
swapoff: /dev/disk1_5: Invalid argument
Synchronizing SCSI cache for disk sda:
FAILED
status = 0, message = 00, host = 1, driver = 00
System halted. で止まらず、
リブートしてから止まる。
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
Waiting for HDD wake up ...
<5> Vendor: SAMSUNG Model: HD501LJ Rev: CR10
Type: Direct-Access ANSI SCSI revision: 03
SCSI device sda: 976773168 512-byte hdwr sectors (500108 MB)
SCSI device sda: drive cache: write back
SCSI device sda: 976773168 512-byte hdwr sectors (500108 MB)
SCSI device sda: drive cache: write back
sda: sda1 sda2 sda4 < sda5 sda6 >
Attached scsi disk sda at scsi0, channel 0, id 0, lun 0
Attached scsi generic sg0 at scsi0, channel 0, id 0, lun 0, type 0
Waiting for HDD wake up ...
it takes . sec for hdd spin up
===== Starting CheckDevices =====
===== Checking RTC...[Success]
[Finished]
linuxrc:choose operation (timeout 4[s])
1:RamRoot other:HddRoot ? -HddRoot-
kjournald starting. Commit interval 5 seconds
EXT3 FS on sda1, internal journal
EXT3-fs: mounted filesystem with ordered data mode.
kjournald starting. Commit interval 5 seconds
EXT3-fs warning: mounting fs with errors, running e2fsck is recommended
EXT3 FS on sda2, internal journal
EXT3-fs: recovery complete.
EXT3-fs: mounted filesystem with ordered data mode.
PRODUCTID=0x0000000B PRODUCTID=0x0000000B
KERNEL:2007/11/13 11:16:1
HDD:2007/11/13 11:16:18
KERNEL:2007/11/13 11:16:14
HDD:2007/11/13 11:16:18
-- CopyFromInitrdToHdd --
........Finish
checking local disk....
fsck 1.38 (30-Jun-2005)
/dev/disk1_1: clean, 17/50288 files, 8845/100390 blocks
fsck 1.38 (30-Jun-2005)
/dev/disk1_2 contains a file system with errors, check forced.
/dev/disk1_2: Inodes that were part of a corrupted orphan linked list found.
/dev/disk1_2: UNEXPECTED INCONSISTENCY; RUN fsck MANUALLY.
(i.e., without -a or -p options)
done
-- linuxrc finished. --
kjournald starting. Commit interval 5 seconds
EXT3-fs warning: mounting fs with errors, running e2fsck is recommended
EXT3 FS on sda2, internal journal
EXT3-fs: mounted filesystem with ordered data mode.
VFS: Mounted root (ext3 filesystem).
Trying to move old root to /initrd ... okay
Freeing init memory: 96K
init started: BusyBox v1.1.1 (2007.11.12-13:48+0000) multi-call binary
Starting pid 690, console /dev/ttyS0: '/etc/init.d/rcS'
--- rcStart (hddroot) ---
===== Starting MountSystemFolders =====
[Success]
===== Starting FreeRamdisk.sh =====
===== Before : 580 KB Free
===== After : 4556 KB Free
===== Result : 3976 KB Freed
[Success]
===== Starting update_file.sh =====
[Success]
===== Starting checkroot.sh =====
mount: /dev/pts already mounted or /dev/pts busy
mount: according to mtab, devpts is already mounted on /dev/pts
ln: /var/spool/cron/cron: File exists
rm: /var/lock/perfmon: is a directory
rm: /var/lock/printing: is a directory
rm: /var/lock/subsys: is a directory
Adding 136512k swap on /dev/disk1_5. Priority:-1 extents:1
[Success]
===== Starting create_devlink.sh =====
[Success]
===== Starting sethostname.sh =====
configure files from Buffalo parameters.
[Success]
===== Starting syslog.sh =====
$Starting system logger:
$Starting kernel logger:
[Success]
===== Starting kernelmon.sh =====
[Success]
===== Starting FanCheckd.sh =====
[Success]
===== Starting setup_time.sh =====
***** Going to ntp server *****
Error : Name or service not known
***** failed to connect to ntp server *****
***** system clock restore from rtc. *****
System Clock setted [Fri May 10 11:35:40 JST 2013]
[Success]
===== Starting EnablingAutoip.sh =====
[Success]
===== Starting restore_config.sh =====
Update configuration files
Restore previous configuration files
[Success]
===== Starting mount_share.sh =====
10+0 records in
10+0 records out
XFS mounting filesystem sda6
share
[Failed ]
===== Starting networking.sh =====
create network files..
IP=[dhcp], netmask=[], dgw=[], dns1=[], dns2=[]
killall: dhcpcd: no process killed
route: SIOC[ADD|DEL]RT: No such process
Configuration network interface: lo eth0
requesting DHCP tout=30[s]
networking.sh: dhcp requesting...
DontDownIface
alwaysFork
eth0: link down
eth0: link up<5>, full duplex<5>, speed 1 Gbps<5>
sendto: count 6 sync 1
sendto: count 5 sync 0
dhcpcd.exe: interface eth0 has been configured with old IP=192.168.2.41 GATEWAY=192.168.2.1
: already running
** networking.sh dhcp fin.
configure files from Buffalo parameters.
[Success]
===== Starting smb.sh =====
configure samba
optarg:samba
Can't Open : /etc/melco/usbshareinfo
load_info ItemValue = off
LoadConfFileString:key=[ad_dns] not found in /etc/melco/info.
LoadConfFileOnOff:key=[info_visible] not found in /etc/melco/info.
LoadConfFileString:key=[msdfs_function] not found in /etc/melco/msdfs.
LoadConfFileString:key=[msdfs_root_as_link] not found in /etc/melco/msdfs.
LoadConfFileString:key=[msdfs_root_name] not found in /etc/melco/msdfs.
LoadConfFileString:key=[msdfs_root_path] not found in /etc/melco/msdfs.
LoadConfFileString:key=[msdfs_link1_name] not found in /etc/melco/msdfs.
Can't Open : /etc/melco/offlinefile
Can't Open : /etc/melco/shareinfo.hidden
Can't Open : /etc/melco/shareinfo.vfs
file:/etc/samba/smb.conf
>IconvCodeCharset CodePage=0,charset=CP932
file:/etc/pam_smb.conf
$Starting SMB services:
$Starting NMB services:
[Success]
===== Starting clientUtil_servd.sh =====
Starting clientUtil_server:starting on eth0
[Success]
===== Starting modules.sh =====
[Failed ]
===== Starting logchkd.sh =====
Starting logchkd:logchkd ver.1.12(Nov 12 2007) started
[Success]
===== Starting daemonwatch.sh =====
Starting daemonwatch:daemonwatch Ver.1.01
watch list file : /etc/daemonwatch.list
[Success]
===== Starting cron.sh =====
Start services: crond[Success]
===== Starting bootcomplete.sh =====
[Success]
Starting pid 1413, console /dev/ttyS0: '/sbin/getty'
BUFFALO INC. LinkStation series LS-LGL(SUIZEI)
LS-LGLFF7 login:
電源が切れているふりして、実は動いているのでは？
そういえば、 PC-P1LAN も電源が切れているふりして実は動いていた。
地球に優しくないなぁ。。。
|
|
← HDD の中身 / inside the hard drive. |
ハックの記録 LinkStation／玄箱 をハックしよう |
→ telnet 可能化 / enable telnetd |
